IPC Series

ꄴPrevious： High-efficiency off-grid inverter
ꄲNext： IU Series

□ Full digital voltage-current double closed-loop control, in high response speed and reliability.

□ Advanced SPWM technology, pure sine wave output, and low Total Harmonic Distortion (THD).

□ No-load loss as low as 13,2W, with a maximum efficiency of 95%, maximizing energy utilization.

□ 6-stage battery charging management function, which can quickly charge the battery and effectively extend its service life.

□ Supporting Bluetooth communication, and view product operation state/real-time data and fault state through mobile app.

□ With mixed load function, inverter power and grid power simultaneously provide the power needed by the load.

□ Complete hardware and software protection functions to ensure stable and reliable operation.





IPC12-3KW

Model：

IPC 12-3KW

Rated Output Power：

3000W

Max. output Power：

6000

Rated output Voltage：

230Vac ±2%

Rated output Frequency：

50/60HZ

AC Input Voltage：

180-265Vac

AC Input Frequency：

45~65Hz

Rated Battery Voltage：

12V



IPC24-3KW

Model：

IPC 24-3KW

Rated Output Power：

3000W

Max. output Power：

6000w

Rated output Voltage：

220VAC/230VAC(default)/240VAC(±2%)

Rated output Frequency：

50/60HZ

AC Input Voltage：

180-265Vac

AC Input Frequency：

45~65Hz

Rated Battery Voltage：

24V



IPC48-3KW

Model：

IPC48-3KW

Rated Output Power：

6000W

Max. output Power：

12000W

Rated output Voltage：

220VAC/230VAC(default)/240VAC(±2%)

Rated output Frequency：

50/60HZ

AC Input Voltage：

180-265Vac

AC Input Frequency：

45~65Hz

Rated Battery Voltage：

48V
